Automatic water shutting off in the house when leakage detected
2 min readHere we will create a system to automatically shut off the water in the house when water leak appears. We will do that without any changes in the water supply system, i.e., we don't need to call the specialist to replace our existing water valve.
$17.00 - $24.29from 2 sellers
Aqara IP67 Water Immersing Sensor
Aqara
Water immersing sensor with an IP67 protection rating, perfect for detecting water levels in ponds, pools, and other water sources. The sensor is easy to install and can be used with Home Assistant or other home automation systems.SJCGQ11LM
(not available)
Xiaomi Mijia Smart Gateway 3 - Mi Home Hub, ZigBee, WiFi, Bluetooth Compatible
Xiaomi
Xiaomi Mijia Smart Gateway 3 is a smart home hub that supports ZigBee, WiFi, and Bluetooth protocols, allowing you to connect and control all your smart devices through the Mi Home app.ZNDMWG03LM
Here we will create a system to automatically shut off the water in the house when water leak appears. We will do that without any changes in the water supply system, i.e., we don't need to call the specialist to replace our existing water valve.
It will cost around $50-60 (depends on your country and exact components used, and if you already have smart home gateway). This smart home system should close water in the house when one of wireless water leak sensorswater leak sensors is detecting leakage, and send notification to the smartphone.
Components used in this video:
-
Actuator for Motorized Valve: https://s.click.aliexpress.com/e/_oFvVMiJ or https://s.click.aliexpress.com/e/_ompGhXV (I used 220V version with 3 wires, unfortunately cannot find exactly the same now). The price should be around $20.
-
Aqara 2 Channels Wireless Relay Controller ($20 or less): https://s.click.aliexpress.com/e/_on8HWYL
-
Aqara water leak sensor (be sure that it compartible with Mi Home!), about $18: https://s.click.aliexpress.com/e/_oDJjG6X
-
Gateway: https://s.click.aliexpress.com/e/_olvy6Sr (required only one for all smart home devices, here is cheapest, start from $10, but try to find much better Xiaomi Gateway 3Xiaomi Gateway 3, else check that it is compatible with Xiaomi Mi Home). Xiaomi Gateway 3 will allow using Mi Home components with Home Assistant if you extend your smart home functionality, so it is the best option.
